Cicognani Speciale Double Decker 1959 Overdrive Pedal

inga recensioner ännu

Utgången, den här produkten kan inte längre beställas.

Inga alternativ hittades
bax-shop.uk | B-stock
Cicognani Speciale Double Decker 1959 Overdrive Pedal
Produktnr.: 9000-0091-2118

Produktinformation

Allmänt

Cramming the sound of a vintage amplifier dosed up with some hefty overdrive into a tight dual stompbox, the Cicognani Speciale Double Decker 1959 supplies a mass of sonic aids as well as blistering valve-driven sound. The two channels can be set up to trigger everything from a light crunch to full-out leads, while the extra clean channel and solo boost serve as handy functions on the side.

The Cicognani Speciale Double Decker 1959: Versatile Inspiration

A fully loaded control panel provides in-depth control over the output of this overdrive pedal, and when it's teamed up with your amp, you're set up with two channels plus solo mode, and three channels plus solo mode when hooked up directly to an audio interface and recording software. The built-in FX loop ensures seamless integration with the rest of your rig, and for maximum versatility and ease, the solo boost can still be activated after the true-bypass switch has been hit.

Specifikationer

Produktfunktioner

Adapter medföljer
Nej
Center negativ/positiv
Centernegativ
Sustainable product
Not specified
Minipedal
Nej
True bypass
Ja
Typ av adapterkontakt
Barrel 2,1 mm
Typ av distortion
Overdrive
Variabel voltage
Nej
Batteriförsörjning möjligt
Nej
Voltage
9V, 12V
Rörförsedd
Ja

Vikt och mått inkluderar förpackning

Vikt
1,4 kg
Mått
25,5 x 15,0 x 7,5 cm

Produktspecifikationer

  • Cicognani Speciale 'Double Decker' 1959
  • overdrive pedal
  • power in: 9 to 12V DC (Centre Negative)
  • power consumption: 300 to max. 500mA
  • S/N ratio: 58dB
  • max. gain: +/- 99 dB
  • boost: 0 to +6db
  • input impedance: <1M Ohm
  • output Impedance: 100 kOhms
  • send impedance: 47 kOhms
  • return impedance: 47 kOhms
  • rec out impedance: <47K Ohm
  • serial Loop FX: 0db
  • parallel Loop FX: +4db
  • max. return signal: 1Vpp
  • max. rec out signal: 0.5Vpp
  • weight: 0.7 kg
  • dimensions: 220 x 130 x 50mm (8.6" x 5.1" x 1.96")
  • ports: main power (DC 2.1mm)
  • guitar input: 6.3mm mono jack
  • amp output: 6.3mm mono jack
  • send/return/rec out: 6.3mm mono jack
  • bypass function: 1) Full Range - 2) Equalized (Rec Out)
  • controls CH1: Max Gain (70db) Volume (+10db)
  • tone stack CH1: Treble (6500Hz +/- 10db) Middle (820Hz +/- 8db) Bass (110Hz +/- 8db)
  • controls CH2: 1/2 12AU7B Max Gain CH2 (100db) Volume (+10db)
  • tone stack CH2: Treble (6500Hz +/- 10db) Middle (820Hz +/- 8db) Bass (110Hz +/- 8db)
  • control boost: level (0/+6db) linear (Full Range)
  • rec out emulator: SM57 mike and 2X12" V30 speaker

Bax Music Garanti Denna produkt levereras med 2 års garanti.
